Installation of a Talon Aerospace Anti-Collision Light
Overview
Introduction
The 1st FAA Certified LED Anti-Collision Light for Commercial Aircraft
Dependability, Weight Savings and Inventory Reduction
The Talon Aerospace anti-collision centerline/fuselage strobe light is designed to replace all incandescent based centerline lights installed on Boeing, Airbus, McDonnell/Douglas, Embraer, Bombardier and other regional aircraft.
During retrofit the operator will purchase an install kit, which includes an adaptor and harness assembly. On airframes that have accessibility provisions inside the interior the upper centerline light allows removal from inside the cabin. The harness and adaptor will last the lifetime of the airframe.
Talon and Proponent
Proponent is the exclusive global distributor of all Talon Aerospace products. This relation provides customers with the latest generation of LED lights.
Proponent is the new identity representing Kapco Global and Avio-Diepen as one united company, and the unique capabilities that the new organization brings to the aerospace market. With extensive experience in supporting the MRO, OEM and airline markets, our organization offers innovative inventory and supply chain management solutions to OEM and aftermarket customers.
Your needs
Durability
Qualified to meet FAR intensity requirements at 30,000 in service hours
After 30,000 hours in service operator can replace LED light boards and is not required to replace complete unit, reducing cost of ownership.
Easy replacement
Single LRU part number allows for both upper and lower centerline light installation across multiple fleet types
Your benefits
- Integrated power supply
- Single LRU part number allows for both upper and lower centerline light installation across multiple fleet types
- Single LRU Partnumber allows for reduced and simplified inventory
- Qualified to meet FAR intensity requirements at 30,000 in service hours
- Polycarbonate lens material covered with diamond carbon coating reduces abrasion and FOD damage
- Average weight saving of 7.5lbs per anti-collision light/power supply combination
- Reducing cost of ownership
Product Description
LED Anti-Collision Centerline/Fuselage Strobes
The Talon Aerospace anti-collision centerline/fuselage strobe light is designed to replace incandescent based centerline lights.
Specifications:
- Part number: TAE0328-2
- Operating voltage: 115 V AC
- Weight: 1.67 lbs (0.76 KG)
- End-of-Life:30,000 hours
- Certification: FAA/EASA/TC
- Light Output: 700 Candela
Eligibility: Airbus A300, A310
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 2LA455010-00/-40
Power Supply: 8ES003761-00, 8ES003974-00
Eligibility: Airbus A318, A319, A320, A321, A330, A340
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 2LA455010-00/-40
Power Supply: 8ES005045-00, 8ES455012-00/-06
Eligibility: Boeing 717, DC-9, MD-88, MD-90
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 30-1098-1, 30-1099-1, 09033308-1, 09033309-1
Power Supply: 09033303-1 (B717U), 09033304-1 (B717L)
Eligibility: Boeing, DC/MD-10, MD-11
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 2LA003968-40
Power Supply: N/A
Eligibility: Boeing 737 Classic
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 30-0837-X, 30-1401-X, 058000-X
Power Supply: N/A
Eligibility: Boeing 737NG
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 30-2505-X (1,3), 30-2506-X (1,3)
Power Supply: 60-4983-3
Eligibility: Boeing 747-400
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA Pending
Replaced OEM Part Numbers:
Anti-Collision Light: 30-1526-X (9, 11)
Power Supply: 60-3368-7
Eligibility: Boeing 757, 767
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA
Replaced OEM Part Numbers:
Anti-Collision Light: 30-1526-3
Power Supply: 60-3368-5,7,7M
Eligibility: Boeing 777
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA Pending
Replaced OEM Part Numbers:
Anti-Collision Light: 30-2335-3
Power Supply: 60-4791-3
Eligibility: Embraer 170, 175, 190, 195
Location Approvals: Fuselage, Centerline, Upper and Lower
Approvals: FAA, TC, EASA Pending
Replaced OEM Part Numbers:
Anti-Collision Light: 30-2906-1
Power Supply: 60-5127-1
Your benefits
- Integrated power supply
- Single LRU part number allows for both upper and lower centerline light installation across multiple fleet types
- Single LRU Partnumber allows for reduced and simplified inventory
- Qualified to meet FAR intensity requirements at 30,000 in service hours
- Polycarbonate lens material covered with diamond carbon coating reduces abrasion and FOD damage
- Average weight saving of 7.5lbs per anti-collision light/power supply combination
- Reducing cost of ownership
