VHF Antenna products Sensor Systems Inc.
Overview
Introduction
S65-8262-12: All metal communications antenna.
Light weight, low drag in a rugged design package.
Resistant to erosion and impact. DC grounded to provide lightning protection, eliminates "P" static. Hermetically sealed. The antenna is 25% shorter and 30% lighter than the S65-8262-2, but keeps the identical mounting footprint. Other models available with optional internal low pass filtering system to prevent VHF interference to the Global Positioning System (GPS). Total harmonic attenuation greater than 80 dB.
Your needs
- Replacement of current Antennes on your fleet.
- Avio-diepen keeps stock on many different Antennes, so delivery will be in 1 day.
- TSO high Quality Approved Antennes from Sensor System Inc. against a excellent pricing level
Your benefits
- High quality Antenna products against an excellent pricing level.
- All metal communications antenna.
- Light weight Antenna
- low drag in a rugged design package
- DC grounded to provide lightning protection, eliminates "P" static
Product Description
FEDERAL & MILITARY SPECS: FAA TSO C37b and C38b. DO-160, MIL-STD-810, MIL-E-5400,
MIL-E-5272, MIL-A-7772 (ASG), MIL-A-6271,
MIL-A-9094.
ELECTRICAL
Frequency ....................118-137 MHz
VSWR ...........................2.0:1
Pattern ..........................Omni/AzCos/El
Polarization ..................Vertical
Impedance ...................50 ohms
Power ...........................100 watts
Lightning Protection ...DC grounded
MECHANICAL
Weight ..........................2.7 lbs.
Height ...........................13.50 in.
Material .........................A356-T61 aluminum casting
Finish ............................Skydrol resistant enamel
Connector ....................C
Drag ..............................1.8 lbs. Mach .85 @ 35,000 ft.
ENVIRONMENTAL
Side Load .....................12 psi
Temperature .................-65°F to +185°F
Vibration .......................14 G’s
Altitude .........................60,000 ft.
